BETA XXL BETA XXL bike rack with a freely selectable number of spaces, single/double‑sided

BETA XXL bike rack with a freely selectable number of spaces, single/double-sided

The BETA XXL bike racks are the high-end versions of the BETA BASIS series. The aim of the BETA XXL series is to offer the classic bike stand in high quality yet cost-efficiently.

Make the most of the BETA XXL bike rack: it is designed as a double parker with access from both sides, and the number of spaces is freely configurable.

The modular design remains the hallmark of the BETA range, and different wheel spacings are available. This makes the BETA XXL far superior to the classic bike stand – including on cost. Compared with stands or cheap wheel clamps, the BETA XXL stands out, not least because its base frame means it needs no foundations, unlike classic stands, and can be set up free-standing. The optional FOCUS element perfects the BETA XXL: the bike always leans against the main hoop.

Screws/wall plugs for final installation are NOT included – only those for assembling the bike rack itself.

* Bicycles are shown for illustration only and are not included.

Product description

The BETA XXL bike rack is designed as a double parker with access from both sides; single-sided use is also possible on request.

Mounting either bolted to the floor, set in concrete or free-standing; all fastening elements for assembling the bike rack itself are included.

The BETA XXL bike rack fits all common bicycles and can be extended with further spaces at any time, single- or double-sided.

The BETA XXL has many applications: residential complexes, medical practices and hospitals, leisure facilities, office and administrative buildings, schools and universities, stations and stops, hotels and restaurants, cultural venues

Planning aid

The BETA XXL bike rack can be extended by any number of spaces. Besides single- or double-sided access, you can add the FOCUS option so that bikes take a fixed position in the space. FOCUS is an element on the support hoop that automatically positions the wheel at the perfect angle as it is pushed in.

Mounting options: bolted down, set in concrete or free-standing

Use our calculator to work out exactly how many spaces you need:

By length: Calculator by length

By number of spaces: Calculator by number of spaces

Mounting options

The BETA XXL bike rack can be fastened and mounted by:

Floor mounting (bolted down)

Floor mounting (set in concrete)

Free-standing (no floor anchoring)

Technical data

BETA XXL:

Technical drawings

All BETA XXL models:

Bike access: single- and/or double-sided

Wheel spacing: 360 / 400 / 500 mm (low/high), 600 / 700 / 800 mm (low); all spacings available

Finish: hot-dip galvanised steel, or hot-dip galvanised and powder-coated

Floor anchoring: bolted down, set in concrete or free-standing

Weight: 5 kg per unit

Mounting height: 680 mm

Colour: galvanised, therefore silver-grey

Construction: round-tube hoop

Reference installations

City of Mengen (DE)

City of Friedrichshafen (DE)

City of Kempten im Allgäu (DE)

City of Ingolstadt (DE)

City of Munich (DE)

City of Lindau (DE)

City of Ravensburg (DE)

City of Rosenheim (DE)
